Setup Of The Card Access Controller; Controller Board Description - Mircom TX3 Series Installation Manual

This chapter describes the installation and setup of the controller and card reader.
This chapter explains
•
•
•
•
•
•
•
•
•
•
•
•
•
•
4.1

Controller Board Description

The Card Access System controls access points according to how the inputs and
outputs are defined and correlated with each other. Inputs and outputs are defined
by how the access and control points are wired with the controller.
Before you begin you must establish how you want the outputs to behave as a
function of the inputs. For a complete description of correlation and the modes of
operation see section 2 on page 13.
Keep a record of the wiring for configuration purposes.
UL Listed TX3-CX Card Access System Installation Manual
Version 2
LT-6906 Copyright 2019
4
Setup of the Card Access
Controller Board Description
Optional Components
Power Supply Connection
TX3-PS24-5A Power Supply (not permitted in UL 294 applications)
RS-485
USB Port
Inputs
Outputs
Card Readers
Setting DIP Switches SW2
Setting Jumpers
Turning on the Controller
Updating Firmware
Beginning Configuration
Controller
