3.2
The TX3-CX-2-A Enclosure
The TX3-CX-2-A enclosure mounts with four screws as shown in figure 5. The
back cover is 12 inches wide by 14 inches long. The top two mounting holes are
10 inches apart.
Figure 5.
UL Listed TX3-CX Card Access System Installation Manual
Version 2
LT-6906
Copyright 2019
12"
10"
Enclosure dimensions for TX3-CX-2-A
Mechanical Installation
Tamper Switch
12.4"
14"
Ground Terminal
27
