Mechanical Installation; Grounding The Card Access System - Mircom TX3 Series Installation Manual

This chapter describes the installation and setup of the controller and card reader.
This chapter explains
•
•
•
•
•
3.1

Grounding the Card Access System

Grounding reduces the risk of electrical shock by providing an alternate escape
route for the electrical current. The Card Access System is equipped with a
16 gauge electrical wire attached to the panel chassis ground terminal. The
ground terminal is shown in figure 6.
Note:
Attach the end of the supplied wire to a suitable grounding wire 16 gauge or
thicker. Attach the other end to the cold water ground.
