Analog Devices ADSP-21364 EZ-KIT Lite Manual page 80

A
1
2
3
3.3V
C22
0.01UF
805
4
74LVCU04
A
B
J8
RCA
CON012 C1
SPDIF 1X1 0.01UF
805
COAX 2 SPDIF_COAX_IN
INPUT
1
R4
75
1206
DAIP1_SPDIF_OUT
HEADER FOR LOOPBACK TEST ONLY
P1
1 2
SPDIF_COAX_IN SPDIF_COAX_OUT
IDC2X1
2X1
B
R17
10K
805
R8
100
1206 U3 U3
1 2 3 4
74LVCU04AD 74LVCU04AD
SOIC14 SOIC14
R125
100K
1206
C21 R63
0.1UF 249
U3 U3 805 805
9 8 11 10
74LVCU04AD 74LVCU04AD
SOIC14 SOIC14
C
R9
0.00
805
DAIP18_SPDIF_IN
J9
RCA
CON012
1X1 SPDIF
SPDIF_COAX_OUT 2 COAX
OUT
1
R112
107
805
ANALOG
DEVICES
ADSP-21364 EZ-KIT Lite
Title
SPDIF CONNECTORS
Size Board No.
C
Date 9-8-2004_8:15
C
D
1
2
U3
5 6
74LVCU04AD
SOIC14
U3
13 12
74LVCU04AD
SOIC14
3
DNP = Do Not Populate
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
Rev
A0190-2004
1.1
Sheet 8 of 12
D
