Hardware Breakpoints

Hardware breakpoints work similarly to watchpoints. Set hardware break-
points on:
• Data transfers within a user-defined memory range
• Instructions
• Register reads and writes
To enable hardware breakpoints for ADSP-21364 processors:
1. From the Settings menu, choose Hardware Breakpoints.
2. The Hardware Breakpoints dialog box appears. The dialog box has
three tabbed pages: Data, Instruction, and Other
Figure 1-3. Hardware Breakpoints Dialog Box
Refer to the following sections for information about breakpoint types.
• "Data Hardware Breakpoints" on page 1-16
• "Instruction Hardware Breakpoints" on page 1-17
• "Other Breakpoints" on page 1-18
Regardless of the breakpoint type, all of the breakpoints share the
attributes and option settings described in:
• "Common Hardware Breakpoint Attributes" on page 1-19
• "Global Hardware Breakpoint Options" on page 1-19
ADSP-21364 EZ-KIT Lite Evaluation System Manual
Using EZ-KIT Lite
(Figure 1-3).
1-15
