• Synchronous Random Access Memory (SRAM)

512 Kbit x 8-bit

• Flash Memory

1M x 8-bit

•

Serial Peripheral Interconnect (SPI) Flash Memory

512 Kbit

• Analog Audio Interface

AD1835A codec

4x2 RCA phono jack for 4 channels of stereo output

2x1 RCA phono jack for 1 channel of stereo input

Headphone jack for 1 channel stereo output

• Digital Audio Interface

RCA phono jack output

RCA phono jack input

• LEDs

12 LEDs: 1 power (green), 1 board reset (red), 1 USB reset

(red), 1 USB monitor (amber), and 8 general purpose

(amber)

• Push Buttons

5 push buttons: 1 reset, 2 connected to DAI,

2 connected to the

ADSP-21364 EZ-KIT Lite Evaluation System Manual

pins of the processor

FLAG
