3. Plug the provided power supply into
Visually verify that the green power LED (
that the two red reset LEDs (
and then go off, and, finally,
4. Connect one end of the USB cable to an available full speed USB
port on your PC and the other end to
EZ-KIT Lite board.
Installation and Session Startup
For correct operation, install the software and hardware in the
order presented in the VisualDSP++ Installation Quick Reference
Card.
To start up an EZ-KIT Lite session in VisualDSP++:
1. Verify that the yellow USB monitor LED (
USB connector) is lit. This signifies that the board is communicat-
ing properly with the host PC and is ready to run VisualDSP++.
2. From the Start menu, navigate to the VisualDSP++ environment
via the Programs menu.
If you are running VisualDSP++ for the first time, the New Session
dialog box appears on the screen (skip the rest of the procedure and
go to step 3).
If you have run VisualDSP++ previously, the last opened session
appears on the screen.
To switch to another session, via the Session List dialog box, hold
down the Ctrl key while starting VisualDSP++ (go to step 5).
3. In Debug target, select EZ-KIT Lite (ADSP-21xxx).
In Platform, select ADSP-21xxx EZ-KIT Lite.
In Processor, choose the appropriate processor, ADSP-21364.
In Session name, type a new name or accept the default.
ADSP-21364 EZ-KIT Lite Evaluation System Manual
on the EZ-KIT Lite board.
J7
LED10
and
) go on for a moment
LED9
LED12
are continually blinking.
LED8–1
on the ADSP-21364
P4
LED13
Using EZ-KIT Lite
) is on. Also verify
, located near the
1-5
