Chapter 2
J23
JP2
J14
J20
Key:
J1 - PC/104 Plus
J2 - PC/104
J3 - Serial COM1
J4 - Serial COM2
J11
J5 - Serial COM3
J6 - Battery
J7 - Power
J8 - SATA0
J9 - SATA1
J10 - Gigabit Ethernet
J11 - Gigabit Ethernet LED
J12 - Not supported (On bottom side)
J14 - Do Not Populate
J15 - Keyboard and Mouse
J16 - USB0 and USB1
J17 - USB2 and USB3
J18 - GPIO
J19 - Video (LVDS and VGA)
J20 - SMBus
J22 - Fan
J23 - Utility
J24 - DDR3 SODIMM
JP2 - LVDS Voltage Select (See jumper table)
JP3 - Serial 2 RS-485/422 Termination (See jumper table)
JP4 - Serial 1 RS-485/422 Termination (See jumper table)

Figure 2-6. Header, Connector, and Socket Locations (Top Side)

12
J19
J5
DCBA
J24
J1
J10
J16
Reference Manual
J4
J3
J22
J6
J17
J9
Product Overview
J15
JP3
JP4
BA
CD
J2
J7
J18
J8
CoreModule 745
