Chapter 3
Video (VGA/LVDS) Interface
The CPU provides the graphics control and video signals to the traditional glass CRT monitors and LCD flat
panel displays. The video features are listed below:
VGA features:
•
Supports maximum resolutions of 1400x1050 at 60Hz or 2048x1536 at 60Hz
•
Provides 2D registers for added color, depth, resolution, and hardware acceleration
•
Provides integrated 3 x 8-bit DAC with R, G, and B signals to the monitor
LVDS features:
•
Integrated single LVDS channel supporting resolution up to 1280x800 or 1366x768
•
Supports 1 x 18 data format
•
Supports transmit clock frequency ranges from 25 MHz to 112 MHz
Table 3-10
lists the pin signals of the video (LVDS/VGA) header, which provides 30 pins, 2 rows, odd/even
pin sequence (1, 2) with 0.079" (2mm) pitch.
Table 3-10. Video Interface Pin Signals (J19)
Pin #
Signal
1
+12V
2
VCC_LVDS_CONN
3
GND
4
GND
5
LA_CLK_P
6
LA_CLK_N
7
LA_DAT2_P
8
LA_DAT2_N
9
LA_DAT1_P
10
LA_DAT1_N
11
LA_DAT0_P
12
LA_DAT0_N
13
LBKLT_CTL
14
LVDD_EN
15
LDDC_CLK
16
LDDC_DATA
17
LBKLT_EN
18
NC
19
CON_DAC_SDA
20
CON_DAC_SCL
21
CON_DAC_RED
22
RED_RETURN
23
CON_DAC_GREEN
24
GREEN_RETURN
25
CON_DAC_BLUE
26
BLUE_RETURN
27
CRT_HSYNC
28
Description
+12 volts for flat panel and backlight
JP2 determines LVDS voltage (+3.3V or +5V)
Ground
Ground
LVDS Clock Positive
LVDS Clock Negative
LVDS DATA Positive Line 2
LVDS DATA Negative Line 2
LVDS DATA Positive Line 1
LVDS DATA Negative Line 1
LVDS DATA Positive Line 0
LVDS DATA Negative Line 0
Panel Backlight Control
Enable Panel Power
Display Data Channel Clock
Display Data Channel Data
Enable Backlight Inverter
Not Connected
Digital to Analog Converter DDC (Display Data Channel) - Data
Digital to Analog Converter DDC (Display Data Channel) - Clock
Digital to Analog Converter – Red Output to the CRT
VGA Ground for Red Output
Digital to Analog Converter – Green Output to the CRT
VGA Ground for Green Output
Digital to Analog Converter – Blue Output to the CRT
VGA Ground for Blue Output
Horizontal Sync – Digital Horizontal Sync Output to the CRT
