UNPACKING THE VENDING MACHINE

The operations described here below must be
carried out only by the personnel who have a
specific knowledge of the machine operation
from the point of view of electric safety and
health rules .
After having unpacked the machine, make sure that
the equipment and the capsule canister are intact.
In case of doubt never use the equipment.
No packing material (plastic bags, foam polysty-
rene, nails, etc . ) should be left within the reach
of children since they are potential sources of
danger .
Packing materials shall be disposed of in authorised
dump sites and recyclable ones collected by spe-
cialised companies.

POSITIONING MACHINE

Installation and any subsequent maintenance
operation must be carried out when the machine
is live and, therefore, by the personnel skilled
and trained on the use of the machine as well as
aware of the specific risks such a condition may
involve .
The machine is not suitable for installation out-
doors . It must be installed in a dry room at a
temperature ranging from 5°C to 35°C . It can
not be installed in a room where water jets are
used for cleaning (e .g . large kitchens, etc . . . ) .
The machine can be installed near a wall, but in
such a way that the back is min . 4 cm . far from
the wall in order to provide for regular ventila-
tion . It shall never be covered with pieces of cloth
or alike .
The machine must be arranged in such a way
that the maximum inclination will not exceed 2° .
The machine is accessed at the back in case of
extraordinary maintenance and/or repair . As a
consequence, it shall be possible to rotate the
machine around itself in order to disassemble
the back .
The machine can be arranged on a table or any
other proper support (recommended height 80
cm) . It is recommended to arrange an easily
cleanable impermeable protection beneath the
vending machine to collect any accidental prod-
uct fall .

INSTALLATION

When the machine is in its final working position:
Cut the clamp securing the door key to the drip
tray grilled cover.
Insert the door key into the lock.
Rotate it and open the door.
Remove the envelope of documents and labels.
Take the power supply cable.
Lift the machine cover and remove the guards
intended to fasten product containers for trans-
port.
