➤ PROGRAMMING KEY

Press key "2" when the display shows "key n" to
scroll the variables composing the function of that
key (by pressing keys "3" and "7").
• If you press "2" when "DISABLED", the key will
be inhibited and it will perform no function.
• If you press "2" when "ENABLED", the key will
perform the function you have programmed
(dispensing cycle of a drink).
Use key "2" to scroll the following items:
The first programmable parameter for each selection
button is coffee in capsules. The following two varia-
bles are available:
• the water quantity in the cup; change it by means
of "3" and "7". If the variable is zero, no espresso will
be dispensed (drink composed by instant products
only);
COFFEE DOSE
• coffee will be dispensed before (value 1) or after
(value 0) instant products.
COFFEE SEQUENCE
FIRST=1
If this option is enabled, after the capsule has been
drilled, the pump will dispense a small water quan-
tity for one second, it stops for the seconds set up
here (from 01 to 15) and it resumes the usual dis-
pensing cycle.
PREINFUSION PAUSE
PROGRAMMING
Scrolling with "2" you can change the product pa-
rameters.
Press keys "3" and "7" to change the rotation time
of the N product motor, thus changing the prod-
uct quantity you have dispensed. If time is zero, no
product N will be dispensed.
PRODUCT
SECONDS:
If the time you have programmed is other than zero,
the N product motor will be activated at the expiry
of the delay time you have programmed; the delay
time is increased or decreased by pressing keys "3"
and "7".
START DELAY
PRODUCT N
The rotation time of the product motor can be
briefly interrupted one or two times during the dis-
pensing cycle (0 = no break). Maximum two breaks
are possible, increased or decreased by pressing
keys "3" and "7";
To determine the solenoid valve opening time and
then the water quantity it will deliver. You can carry
out a "time test" on the setpoint.
WATER TIME
CC: 00
0=DISABLED
Water will be dispensed in the mixing bowls at the
expiry of the delay time you have programmed.
START DELAY
WATER N
The rotation time of the mixer fan can be changed
by pressing keys "3" and "7". If time is equal to zero,
the mixer will not rotate.
MIXER
0=DISAB.
0.0
0.0
BREAKS NUMBER
0.0
EN
N
0.0
0
N
0.0
0.0
N
