EN
Extract the mixer fan just by pulling it.
Check the wear state of the w-ring sheathing the
mixer motor shaft. Replace if worn.
Wash the assembly of disassembled parts with plen-
ty of lukewarm water.
To replace the blender motor follow the procedure
below:
Remove the silicone tubes intended to dispense the
product.
Turn the orange ring nut clockwise and pull the mix-
ing bowl body.
Unscrew the crosshead by using a PH2 screwdriver
and extract the motor.
The power supply wires can be removed without any
tool.
34
MAINTENANCE AND CLEANING

PRODUCT CANISTERS

Turn to closed position the product chute faces.
Remove the product containers, lifting them from
the front side and pulling them outwards; remove
the cover and empty the residual product, remove
the faces from the containers and wash them in
abundant lukewarm water.
