EN
Before starting to install and use the machine, it is
necessary to carefully read and understand the con-
tent of the documentation since it can supply im-
portant information on installation safety, utilisation
rules and maintenance operations.
IDENTIFICATION OF THE MACHINE
AND ITS FEATURES
Each device is identified by a specific serial num-
ber, indicated on the data plate located on the right
side. The plate is the only one recognised by the
manufacturer and it contains all the data that enable
the manufacturer to supply technical information of
any kind in a quick and safe manner and to facilitate
the management of spare parts.

TECHNICAL FEATURES

• Height: 560 mm
• Height: (with upper panel up: 835 mm)
• Width: 310 mm
• Depth: 420 mm
• Depth (with open door: 630 mm)
• Weight: 21 Kg
• Power supply voltage: 220-240 V
• Power supply frequency: 50 Hz
• Installed power: 1300 W
• Pressure level: > 70 dB

SALES PRICES

For each selection a different programmable price
can be set. The standard setting has the sales price
equal to zero for all selections.

POSSIBLE ADJUSTMENTS

Espresso: water dose
Instant: time-based instant and water doses.
Temperature: adjustable of firmware.

APPROVALS

• water presence;
• capsule presence;
• brew unit position;
• liquid waste empty;
• operation temperature reached;
• count of the number of used capsules.
8

GENERAL INFORMATION

SAFETY

• Energy
• main switch 230 V ac
• door switch 230 V ac
• two fuses 6,3x32 mm 12 A time-delay
• Heat
• manually resettable sensors 127° C
• vibration pump with thermal cut out 110° C
• Software
• time limits for water dispensing cycles

ELECTRIC ENERGY CONSUMPTION

The electric energy consumption of the machine
will depend upon many factors such as the temper-
ature and ventilation of the room where the ma-
chine is installed, the inlet water temperature, the
boiler temperature, etc...

TRANSPORT AND STORAGE

To avoid damaging the machine, loading and
unloading operations shall be performed with
great care . It is possible to lift the machine by
means of a motor-driven or manual lift truck
by positioning the forks beneath the machine .
Please avoid:
• overturning the machine
• dragging the machine by means of ropes or
alike
;
• lifting the machine by its sides
• lifting the machine by means of slings or ropes
• shaking or impacting the machine and its
package
.
For storage it is necessary to keep the room dry
at a temperature between 5 and 35 °C . With the
original package never stack more than 2 ma-
chines and never forget to keep the vertical posi-
tion specified by the arrows on the package .
The transport and handling of the machine should
always be carried by two operators .
;
;
;
