➤ SOFTWARE UPDATE

Create a "rhea" folder on a USB support.
Create a "cpu05" folder inside the "rhea" folder and
transfer the file in the new version into this folder.
Power off the vending machine, access the display
board inside the door and insert the USB support
into the socket of the display board.
Power on the machine; the display shows "CPU UP-
DATE", press key "4"
Software update sequence:
CPU UPDATE
4=GO "FILENAME"
CPU COPYING
CALIPSO BOOT
PROGRAMMING OK
Power off the machine, remove the USB support,
close the machine again; the new software has been
properly transferred.
At first power-on, standard "1A" factory-set config-
uration is loaded.

➤ DIAGNOSTICS

It checks the sensors in the vending machine:
S-H2O=0
S-SP=0
s-h2o = tank water sensor
(1) active – (2) not active.
s-cas = drawer presence sensor
(1) active – (2) not active.
s-sp = flap sensor
(1) active – (2) not active.
s-cap = capsule presence sensor
(1) active – (2) not active.
24
PROGRAMMING
.
N
S-CAS=0
S-CAP=0
It tests the water circuit of the coffee unit to check
its correct operation:
TEST
HYDRAULIC
Press key "2" to access diagnostics and to enable
the machine to display (keys "3" and "7") the stand-
by message and the water temperature in the ther-
moblock, alternatively.
ENABLE DISPLAY
TEMPERAT. 1=SI
Press "2" once again to display the voltage value in-
tended to supply devices at 24 V dc.
VOLTAGE
VOLT

➤ SALES AUDIT DATA

This menu is intended to gather the quantities of
the selections made by the machine: names are as-
signed according to the EVADTS standard
• VA 102 quantity of total vends (parameter not re-
settable).
TOTAL SELECTIONS
• VA 104 number of sales made after reset, possible
for each selection, including pre-selections. It acts
on all subtotals: "SEL. SUBT." and "SEL. SUBT.:
from 1s to 8L", to reset, press button "3" for abt. 3
seconds.
PART. SELECTIONS

➤ MDB

Use this menu for changing MDB parameters (Re-
fer to Paragraph "PARAMETERS")
• maximum credit
• maximum change
• sale type
3=START
0
00.0
.
000
000
.
