Lucent Technologies SLC 5 Series Manual page 90

363-205-401
Issue 7, March 1997
Power Panel
(Note)
Early Version
Later Version
Note: If the words 51 CABINET POWER PANEL appear at the top of the power
panel, then the power panel is a later version. Otherwise, the power panel is an
early version.
4.
!
DANGER:
High current flow will occur if short is placed across battery terminals. No
attempt should be made to measure battery voltage across terminals.
NOTE:
Eight battery packs are needed if two battery strings are to be installed.
Get four KS-21906, L4 battery packs.
5.
NOTE:
Lower two battery shelves house battery string 1 and upper two battery
shelves house battery string 2 (when installed). If additional battery string
(battery string 3) is required, a 181A apparatus mounting can be installed
in top of battery section to house it.
Place batteries on battery shelves and dress battery cables as each battery
pack is placed on shelf.
Table A
51A Power Panel
Battery Associated
String Fuses
1 (Lower) F3, F4, F5
2 (Upper) F1, F2, F6
1 (Lower) F1, F2, F5
2 (Upper) F3, F4, F6
Power Up: DLP-503
Associated Connector
Jacks Plug
J3, J4 P5, P6, P7, P8
J1, J2 P1, P2, P3, P4
J1, J2 P1, P2, P3, P4
J3, J4 P5, P6, P7, P8
Page 3 of 10
