CIB 3000
34-Button Deluxe Voice Terminal
CIB 3000
Comcode 103-972-972
Issue 2

Advertisement

loading
Need help?

Need help?

Do you have a question about the CIB 3000 and is the answer not in the manual?

Questions and answers

Related Manuals for Lucent Technologies CIB 3000

Summary of Contents for Lucent Technologies CIB 3000

  • Page 1 CIB 3000 34-Button Deluxe Voice Terminal CIB 3000 Comcode 103-972-972 Issue 2...
  • Page 2 CIB 3000 34-Button Deluxe Voice Terminal The 34-button voice terminal (Figure 1) allows access to intercom and outside lines as well as to programmable and other button features that may be provided in your communications system. By attaching a voice terminal power supply, you can also plug in a Hands-Free Unit or other adjunct to this voice terminal.
  • Page 3 ASSEMBLING YOUR VOICE TERMINAL Unpack your voice terminal, which has the following components: voice terminal body handset (with handset cord attached) modular voice terminal cord adjustable desk stand. The desk stand provides three positions for the 34-button deluxe voice terminal: 8 degrees (low), 18 degrees (middle), and 28 degrees (high). Desk Stand Installation NOTE: To avoid pinching your fingers, be sure the adjustable portion of the desk stand is in the low position before installing the voice terminal.
  • Page 4 FIGURE 3 34-Button Deluxe Voice Terminal with Adjustable Desk Stand Attached (Bottom View) Thread one end of a (D8W) modular voice terminal cord between the base of the desk stand and the bottom of the voice terminal and plug it into the jack labeled LINE on the voice terminal. Check to see that one end of the handset cord is attached to the handset.
  • Page 5 Desk Support Base FIGURE 4 34-Button Deluxe Voice Terminal Attached to the Desk Stand Plug the other end of the modular voice terminal cord into the build- ing wiring connection, which may be a modular voice terminal exten- sion cord or a modular voice terminal jack (Figure 5). Modular Voice Terminal Extension Cord Modular Voice...
  • Page 6 9 The angle of the desk stand can be adjusted (Figure 6) by performing the following: Use your left hand to hold the base of the stand firmly to the desk top. To raise the voice terminal, use your right hand to lift slowly on the rear of the voice terminal until the desired position is reached.

  • Page 7: Setting The Volume

    TESTING YOUR VOICE TERMINAL Use the test/program (T/P) switch on the left side of the voice terminal to test the lights and ringer. Slide the T/P switch away from you to the T position (Figure 7). If the voice terminal is working properly, the red and green lights will flash and the set will ring.
  • Page 8 REMOVING AND INSERTING LABELS REMOVING Grasp the silver tab above the touch-sensitive buttons and pull the labels out of the label slot (Figure 8). INSERTING 1 Insert the bottom of the label into the label slot above the column of touch-sensitive buttons (Figure 8).
  • Page 9 HANDSETS FOR THE HEARING IMPAIRED AND NOISY LOCATIONS All voice terminals come with a handset that is hearing-aid compatible. Two other types of handsets are also available: The (R6C3) impaired-hearing handset (31753) has an extra amplifier to provide greater volume in the earpiece. A thumbwheel volume on the handset allows the volume to be turned up or down, as needed.
