Lucent Technologies Mitel SX200D Series Manual

O c t e l 5 0
V o i c e P r o c e s s i n g
M o d u l e
Inband signaling is
used for integration
Supported Voice Processing
Modules
Configuration Note 77135
Mitel SX200D * ONS
Revised 5/6/99
SX
200
Mitel SX-200D ONS
Analog
Ports
Voice Board(s)
1.0 METHOD OF INTEGRATION
Inband signaling is used for integration. Integration is achieved via DTMF
signals passed from the Mitel SX200D to the Octel 50. Call forward to
personal greeting is achieved via DTMF signals passed from the SX200D to
the Octel 50. Message waiting indicators are set or cleared by dialing a
feature access code followed by the extension number. A hookflash
followed by the extension transfers the caller to the operator.
1.1 SUPPORTED VOICE PROCESSING MODULES
The Octel 50 is a Year 2000 (Y2K) compliant, PC based, enhanced voice
messaging product release intended to replace the Smooth Operator,
Smooth Operator Ultra Lite, Smooth Operator Lite and Cooperator product
lines.
Disclaimer: Configuration Notes are designed to be a general guide reflecting Lucent Technologies -
Octel Messaging Division's (OMD) experience configuring its systems. These notes cannot anticipate
every configuration possibility given the inherent variations in all hardware and software products. Please
understand that you may experience a problem not detailed in a Configuration Note. If so, please notify
Sales Engineering at (408) 324-3066, and if appropriate we will include it in our next revision. OMD
accepts no responsibility for errors or omissions contained herein.
Personal Computer
