DO ITEMS BELOW IN ORDER LISTED
4.
NOTE:
Batteries are shipped directly from manufacturer.
Install and test RT batteries in 80D or 80E cabinet skirt:
A. Chloride batteries in 80E cabinet.
B. Lineage 2000 VR Series batteries in 80E cabinet.
C. Lineage 2000 VR Series batteries in 80D cabinet.
D. Chloride batteries in 80D cabinet.
5. Verify connections to ED-83114-30 control & distribution panel.
6. Install power units in rectifier shelf.
7. Install 3C RINGING GENERATORs in ring shelf. (Not required for
FTTH arrangement)
8. Install RCU (ring control unit) in ring shelf. (Not required for FTTH
arrangement)
9.
NOTE:
Each circuit breaker on control and distribution panel
supplies an equipment bay according to the cabinet group
arrangement. To identify circuit breakers, refer to the label
located on the door opposite the Control and Distribution
Panel.
Turn on one circuit breaker and verify the it does not trip. If the cir-
cuit breaker does trip, cabinet wiring trouble must be cleared
before continuing.
10. If the circuit breaker powers RT dual channel bank(s) or
J1C182PB-1 Optics Power shelf, continue with step 11. Other-
wise, proceed to Step 12.
Power Up: NTP-007
Page 3 of 4
FOR DETAILS, GO TO
DLP-524
DLP-525
DLP-534
DLP-535
DLP-526
DLP-527
DLP-528
DLP-529
