DEFINITY
Enterprise Communications Server
Generic 2 and System 85
8434DX Voice Terminal
Quick Reference
555-104-768
Comcode 107985517
Refer to the procedures on this card to use the
features on your 8434DX voice terminal. The features
here are listed in alphabetical order. In the spaces
provided, write in the feature access codes for your
system. For more information about any of these
features, see your system manager or refer to the
®
DEFINITY
Generic 2 and System 85 8434DX Voice
Terminal User's Guide , 555-104-767.
USING THE SOFTKEYS
You can display any of the softkey features by pressing
and then the softkey below the feature
Menu
abbreviation. If the feature you want to use is not on
the bottom line of the screen, press
or
Next
until you see the feature you wish to access.
Prev
When the feature is active, an arrow appears above
the feature. (However, if the feature requires you to dial
a telephone number or extension, such as Call
Forwarding, you will temporarily see the digits you are
dialing, rather than the arrow, above the feature
name.)
CANCELLING FEATURES
In order to cancel or deactivate features, such as
cancelling a LWC message or deactivating Send All
Calls, you must be off-hook.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEFINITY 8434DX and is the answer not in the manual?

Questions and answers

Related Manuals for Lucent Technologies DEFINITY 8434DX

Summary of Contents for Lucent Technologies DEFINITY 8434DX

  • Page 1 All manuals and user guides at all-guides.com ® DEFINITY Enterprise Communications Server Generic 2 and System 85 8434DX Voice Terminal Quick Reference 555-104-768 Comcode 107985517 Refer to the procedures on this card to use the features on your 8434DX voice terminal. The features here are listed in alphabetical order.

  • Page 2: Abbreviated Dialing (Ad)

    All manuals and user guides at all-guides.com ABBREVIATED DIALING (AD) To program/reprogram an AD button 1 Pick up handset. NOTE: For speakerphone users, press a call appearance button or press Speaker 2 Press softkey below Prog or Press Program or Dial AD Program access code _________. 3 Press selected AD button.

  • Page 3: Automatic Callback

    All manuals and user guides at all-guides.com To place a call using an AD list button or access code 1 Press Pers List Grp List Sys List or Dial appropriate AD List access code: • Personal __________ • Group __________ •...

  • Page 4: Call Coverage/Consult

    All manuals and user guides at all-guides.com CALL COVERAGE/CONSULT To answer a call for a coworker for whom you are a coverage point 1 Press call appearance button of the incoming call when ringing begins or green light flashes. To talk privately with a coworker after answering a redirected call 1 Press Transfer...

  • Page 5: Call Pickup

    All manuals and user guides at all-guides.com CALL PARK To park a call at your extension (for retrieval at any extension) 1 Press Transfer 2 Dial Call Park access code _______. 3 Dial Call Park zone number. 4 Dial an idle Answer-Back channel number. 5 Press Recall 6 Press...

  • Page 6: Last Number Dialed

    All manuals and user guides at all-guides.com HOLD To put a call on hold 1 Press Hold To answer a new call while active on another 1 Press Hold 2 Press call appearance button of incoming call. To return to held call 1 Press call appearance button of held call.

  • Page 7: Leave Word Calling (Lwc)

    All manuals and user guides at all-guides.com LEAVE WORD CALLING (LWC) To leave a message after dialing an extension 1 Press softkey below LWC or Press before hanging up your handset. To leave a message without ringing an extension 1 Press softkey below LWC or Press or Dial Leave Word Calling access code _______.

  • Page 8: Select Ring (And Ringer Volume)

    All manuals and user guides at all-guides.com SELECT RING (and RINGER VOLUME) To select a personalized ring 1 If your 8434DX has a button, press Shift Shift and then press Hold if your 8434DX has a Ring button, press Ring •...
  • Page 9 All manuals and user guides at all-guides.com SPEAKERPHONE NOTE: To use this feature, your voice terminal must be set for the Speakerphone (speak and listen) feature. To place/answer a call without lifting the handset, or to use speakerphone with any feature 1 Press Speaker 2 Place or answer call, or access selected feature.
  • Page 10 1 Press Transfer 2 Dial number where call is to be transferred. 3 Press again. Transfer 4 Hang up. Prepared by Issue 2, September 1997 BCS Product Copyright © 1997 Documentation Development Lucent Technologies Middletown, NJ 07748-9972 Printed in USA...
