363-205-401
Issue 7, March 1997
Add Battery String Equipment to J1C182BA Power
Shelf in Frame, 51, 80, or 90-Type Cabinet RT
DO ITEMS BELOW IN ORDER LISTED
1.
NOTE:
This procedure provides steps for adding supporting
equipment (battery strings, rectifiers, battery chargers, and
BFUs) to J1C182BA power shelf. This procedure assumes
the following:
• The procedures to initially equip the J1C182BA power
shelf has been done.
• The outside cable pairs are not closed through to the
RT so that the RT is isolated from the digital and
derived lines.
• The J1C182AB or J1C182AE dual channel bank
assembly has been installed in the frame or cabinet
enclosure.
• The miscellaneous pair panel, protector connectors,
power shelf, fan shelves, and battery shelves (if
required) have been installed in the frame or cabinet
enclosure.
• The acceptance Tab procedures in this volume have
been performed.
This procedure contains instructions concerning the installation of
the various supporting units into the RT assembly shelves, bat-
tery shelves (if required), and power shelf, and for verifying that
the units are operating properly.
Power Up:
Page 1 of 4
FOR DETAILS, GO TO
NTP-004
