16. As shown in Figure 2, place the left 4 batteries (batteries 1 through 4 with
cable assemblies) in battery compartment in position for battery string 1.
Ensure the first and fourth batteries are 1 inch away from the battery compart-
ment doors.
Patch Cord
String # 1
4
3
2
1
Figure 2 – RT Battery Strings and Connections
Main Connector
String #2
String 2
5
8
6
7
7
6
8
5
String 1
Main Connector
String #1
Side 2
Patch Cord
String # 1
4
1
3
2
2
3
1
4
String 3
Patch Cord
String # 2
Main Connector
String #3 Note:
Side 1
Power Up: DLP-535
Page 5 of 8
1 in.
(2.5 cm)
5
6
7
8
1 in.
(2.5 cm)
Leave approximately 1 in. (2.5 cm)
of space per side between batteries
and battery cover panel to avoid
interference when closing.
