Power Up: NTP-004
Page 2 of 4
DO ITEMS BELOW IN ORDER LISTED
2.
Get Support Apparatus Listed:
• 216-type tool (80-type cabinet only),
• Special key (allen-type wrench) - COMCODE 846244168
(51-type and 80-type cabinets only),
• DMM (digital multimeter) with an accuracy of 1.0% and an
ac/dc input impedance of ≥ 1 megohm.
• One AUA11( ) PCU (power converter unit).
3.
!
CAUTION:
An electrostatic discharge wrist strap with a minimum
resistance of 250K Ohms should be worn when handling
Series 5 circuit packs to prevent possible damage to the
circuit packs. Before using the wrist strap, check it for
opens, shorts, and minimum resistance value. If the strap
does not pass these checks it should not be used. To avoid
possible personal injury while using the wrist strap, do not
connect it to the power shelf or adjacent portions of the RT
frame. Connect the wrist strap to ESD GRD jack on the fan
unit, if present. If grounding jack is not present, connect
wrist strap to bare-metal section of the frame well away from
the power shelf.
Verify AC power panel connections for power shelf has been
made and turn on circuit breaker(s).
4.
Perform RT battery installation;
A. in Frame-type RT, 80-type CSC (community service cabi-
net), or 90-type cabinet (ED-7C621-30, ED-97977-30, or
ED-7C699-30) RT.
B. in 51-type (ED-7C601-30) cabinet RT.
363-205-401
Issue 7, March 1997
FOR DETAILS, GO TO
DLP-500
DLP-512
DLP-513
