- Page 1 CIB 2853 (7303H01) 10-Button Voice Terminal (3161) CIB 2853 Comcode 845-655-596 Issue 5...
- Page 2 CIB 2853 (7303H01) 10-Button Voice Terminal (3161) The 10-Button Voice Terminal (Figure 1) allows access to intercom and outside lines as well as to programmable and other button features that may be provided in your communications system. FIGURE 1 10-Button Voice Terminal...
- Page 3 If your voice terminal is to be wall mounted, you should have purchased the (D1-181230) hardware kit for the wall mount separately from the 10- Button Voice Terminal. The kit’s order number (comcode) is 103995882. The three pieces of the desk stand/wall mount are attached to each other (Figure 2).
- Page 4 DESK SUPPORT INSERT INTO BASE FROM TOP OF BASE FIGURE 3 Assembling the Desk Stand 3 Turn the voice terminal upside down. Holding the stand upside down, position the stand on the voice terminal so that the stand’s mounting slots (Figure 4A) fit just below the voice terminal’s mounting tabs (Figure 4B).
- Page 5 Mounting Tabs Mounting Slots Voice terminal Assembled desk stand (bottom view) (top view) Attaching the stand to the voice terminal (bottom view) FIGURE 4 Attaching the Voice Terminal to the Desk Stand Gently slide the stand upward so that the voice terminal tabs fit securely in the three mounting slots on the stand (Figure 4C).
- Page 6 10-Button Voice Terminal Desk Support Base FIGURE 5 10-Button Voice Terminal Attached to the Desk Stand Check to see that the other end of the handset cord is attached to the handset. If it is not, plug it into the handset now. Plug the other end of the modular voice terminal cord into the jack connection (Figure 6) which is one of the following: a modular voice terminal extension cord or a modular voice termi-...
-
Page 7: Wall Mount Assembly
Control unit To voice terminal jack To modular voice Modular voice terminal extension terminal cord cord To modular voice terminal jack FIGURE 6 Connecting the Voice Terminal Cord 10 To remove the voice terminal from the desk stand, set the handset aside, turn the voice terminal upside down, and unplug the modular voice terminal cord. - Page 8 FIGURE 7 Assembling the Wall Mount (Bottom View) Lift the base and push the wall support through the slots until it fits firmly in place. Turn the base over. Using a 3/16” drill bit, enlarge the four mounting screw holes (Figure 2) in each corner of the base.
- Page 9 Red key FIGURE 8 Installing Toggle Bolts for Wall-Mounting the Voice Terminal Insert the red key (provided in the hardware kit) into a toggle bolt, and push with your fingertip (do not force or hammer the red key) to pop open the toggle bolt (Figure 8C). Remove the red key and repeat this procedure for the remaining three toggle bolts.
- Page 10 WALL SUPPORT INSERT INTO BASE FROM REAR OF BASE Top of base FIGURE 9 Wall Mount Attached to the Wall Converting a Voice Terminal for Wall-Mounting Remove the number card retainer with a straightened paper clip or similar device and remove the number card (Figure 10). iss 5, cib2853-9...
- Page 11 Switchhook Button Paper Clip Number Card Retainer FIGURE 10 Removing the Number Card and Retainer Remove the screw under the number card and lift out the handset retainer from the upper housing (Figure 11). Handset Retainer Screw Handset Retainer FIGURE 11 Handset Retainer and Screw 3 Turn the handset retainer upside down and rotate it 180 degrees (Figure 12).
- Page 12 Handset Retainer Removed Handset Retainer Screw Rotate removed to wall mount position FIGURE 12 Rotating the Handset Retainer Replace the handset retainer. When properly inserted, the handset retainer extends out from the handset cradle (Figure 13). Handset Retainer Handset Retainer after Handset rotation...
- Page 13 If the other end of the handset cord is attached to the handset, unplug it now. Position the voice terminal so that its tabs fit just above the mounting slots on the wall mount (Figure 14). Mounting Slots Mounting Tabs (bottom view) (top view) FIGURE 14 Attaching the Wall Mount to the Voice Terminal...
- Page 14 Plug the other end of the handset cord into the handset and place the handset in the cradle. Plug the other end of the modular voice terminal cord into the jack connection (Figure 6) which is one of the following: a modular voice terminal extension cord or a modular voice termi- nal jack.
-
Page 15: Setting The Volume
Setting the Volume The volume control switch is also located on the left side of the voice ter- minal (Figure 15) and adjusts the volume of the ringing and button clicks. Slide the switch away from you to increase the volume. Slide the switch toward you to decrease the volume. - Page 16 Handsets for the Hearing Impaired and Noisy Locations All voice terminals come with a handset that is hearing-aid compatible. Two other types of handsets are also available: The (R6C3) Impaired-Hearing Handset (31753) has an extra amplifier to provide greater volume in the earpiece. A thumbwheel volume control on the handset allows the volume to be turned up or down, as needed.
