SLC‚ Series 5 Remote Terminal 363-205-401 TOP
Figure 2 shows the various feature package arrangements available for the SLC
Series 5 Carrier System.
MC97722A1
BCU
SLC 96 Mode 1 COT
or Mode 1
5ESS SWITCH/DCLU
R
(DIGITAL CARRIER LINE UNIT)
SLC 96 Mode 1 or Mode 2 COT
or Mode 1 or Mode 2
5ESS SWITCH/DCLU
(DIGITAL CARRIER LINE UNIT)
SLC 96 Mode 1 or Mode 2 COT
or Mode 1 or Mode 2
5ESS SWITCH/DCLU
(DIGITAL CARRIER LINE UNIT)
MC97755A1
BCU
FPD requires the J1C182AD and J1C182AE Channel Banks
MC97755A1
BCU
FPB with MC97771A1 BCU, FPC, or FPC-AutoCut
COT and RT Configuration (See Above)
FPB or FPC with AUB27 RT ADU (see above) COT and RT
configuration with J1C182AE RT Channel Bank. Requires
MC977791A1 BCU, AUB27 ADU, and AUA105 TRU units at the RT
5ESS Switch/IDCU
GTD 5EAX
DMS-100
Figure 2 — Feature Package Arrangements
x Issue 7 March 1997
FPA (FEATURE PACKAGE A)
SLC SERIES 5 SLC SERIES 5
R
COT
J1C182AA/AD J1C182AB/AE/AF
FPB (FEATURE PACKAGE B)
(AUB24 RT ADU)
SLC SERIES 5
J1C182AB/AE/AF
SLC SERIES 5
J1C182AB/AE/AF
FPB with Special Service
(AUB27 RT ADU)
SLC SERIES 5
J1C182AB/AE/AF
FPC (FEATURE PACKAGE C)
or
FPD (FEATURE PACKAGE D)
SLC SERIES 5 SLC SERIES 5
RT
J1C182AA/AD J1C182AB/AE/AF
equipped with AUA71 TCUs.
FPC-AutoCut
(AUB27 RT ADU)
SLC SERIES 5 SLC SERIES 5
COT
J1C182AA/AD J1C182AB/AE/AF
FIBER-TO-THE-HOME
with J1C182AE RT Channel Bank
FPF
( SLC -2000 MSDT Feature)
R
FP303R3
MC97723A1
RT
BCU
MC97724A1 FPB/U/M1
RT
BCU FPB/I/M1
FPB/U/M1
FPB/I/M1
MC97771A1
RT
BCU
FPB/U/M2
FPB/I/M2
FPB/SS/U/M1
FPB/SS/I/M1
MC97771A1
RT
BCU
FPB/SS/U/M2
FPB/SS/I/M2
MC97756A1
RT
BCU
MC97771A1
RT
FPC/AC
BCU
900A1
DISTANT
TERMINAL
SLC -2000
MSDT
MC97796A1
SLC Series 5
BCU
RT
AUA112B
J1C182AB/AE/AF
TRU
