Lucent Technologies SLC 5 Series Manual page 504

Conversions: DLP-520
Page 2 of 4
No Protection Line ( NPL )
Mode 2 Operation ( 2 )
AB In-Service ( ABI )
CD In-Service ( CDI )
AB Equipped ( ABE )
CD Equipped ( CDE )
Major Alarm for MISC1 ( 1MJ )
Major Alarm for MISC2 ( 2MJ )
16
Use FS
Use NC
SGL
PA
MJP
Not Used
Not Used
Use DL
Clear Provisioning
(Use CLEAR When ADU is
first installed in a new system)
Table A
AUB27( ) Switch Setting
S1 Switch
1 Protection Line ( PL )
2 Mode 1 Operation ( 4 )
3 AB Preservice ( ABP )
4 CD Preservice ( CDP )
5 AB Unequipped ( ABU )
6 CD Unequipped ( CDU )
7 Minor Alarm for MISC1 ( 1MN )
8 Minor Alarm for MISC2 ( 2MN )
S2 Switch
1 Use 13
2 FE
3 CUT
4 Use DBL
5 Use NPA
6 Use MNP
7 Not Used
8 Not Used
S3 Switch
CLEAR/NORM Plug
S4, S5, S6, and S7 Rotary Switches
System ID Number
S8, S9, S10, and S11 Rotary Switches
Unused (Set to 0)
NDL
Do Not Clear Provisioning
(Use NORM for In-Service
System)
363-205-401
Issue 7, March 1997
