Lucent Technologies SLC 5 Series Manual page 488

363-205-401
Issue 7, March 1997
AUA62C or D and AUA64C or D LIU Transmit/Receive Pad Setting
Inserted
Loss
(dB)
22.5
15.0
7.5
0
* ON when depressed toward the numbers.
6.
!
CAUTION:
Line coding on the digital facility and terminal equipment interfaces
MUST BE THE SAME or service interruptions can result.
Set the line coding switch (S1 on the AUA61C or D or S100 on the AUA62C
or D or AUA64C or D) to B8ZS (Table C).
Table A
AUA61C or D
LIU Equalizer Settings
Distance
to DSX-1
(Feet) 2
0-132 OFF
133-265 OFF
266-398 OFF
399-532 ON
533-655 ON
Table B
Transmit Pad (S400/S1, S2)
Switch Settings
1 2 3
OFF OFF OFF
OFF OFF ON
OFF ON OFF
ON OFF OFF
Equalizer Switch
(S400/S2) Setting
1 0
OFF ON
ON OFF
ON ON
OFF OFF
OFF ON
Receive Pad (S100)
Switch Settings
4 1
ON —
OFF —
OFF OFF
OFF ON*
Conversions: DLP-514
Page 3 of 4
2
—
—
ON*
OFF
