Lucent Technologies SLC 5 Series Manual page 150

363-205-401
Issue 7, March 1997
Add 336A Rectifiers to Existing J1C182BA Power
1. Get required number of 336A RECTIFIERs and inspect for possible physical
damage.
2. Verify that fuse on 336A RECTIFIER(s) (Figure 1) is not blown.
3. Insert one 336A RECTIFIER into first vacant RECT slot (counting right to left)
in power shelf.
4. Is another 336A RECTIFIER to be installed?
If YES, then repeat from Step 2.
If NO, then STOP. YOU HAVE COMPLETED THIS PROCEDURE.
Figure 1 – Location of Fuse on 336A RECTIFIER
Shelf
FUSES
Power Up: DLP-515
Page 1 of 2
Lucent
336A
RECTIFIER
ALARM
