Data bits data_bits
Parity parity
Stop bits stop_bits
InterFrame interframe
Forwarded TCP forwarded_port
port

3.2.2.3 Networks

The "Networks" part is used to configure the 2 Ethernet interfaces (LAN1 and LAN2) available
on the concentrator. These Ethernet interfaces make it possible for the concentrator to belong
to 2 different Ethernet networks.(see section 2.4.5: "Ethernet interface")
Version 2.05
préliminaire
USER MANUAL – WebdynSunPM
• 38400
• 57600
• 115200
• 230400
• 460800
Number of data bits:
• 7
• 8
Serial connection parity:
• None: no parity
• Odd: odd parity
• Even: even parity
Number of stop bits:
• 1
• 2
The waiting time between 2 frames
exchanged on the serial port. This time
is expressed in ms.
See the explanation
"3.1.2.1.3.3 - Serial port configuration"
Forwarded TCP port.
If there is a value in this field, the
concentrator opens a modbusTCP port
on the entered port number.
When modbusTCP devices connect to
this port, all sent requests are directly
forwarded to the modbusRTU bus and
the response is returned to the
connected device using this modbusTCP
port.
This option is used to create a
communication tunnel
modbusTCP devices and the local
modbusRTU network.
The requests are slotted between the
concentrator's internal
requests.
in section
between
monitoring
