Webdyn WebdynSunPM User Manual page 12

5
6
7
12-24 V power supply terminal block
1
2 2 Ethernet ports (LAN 1 and LAN 2)
3 4 0-10 V or 4-20 mA analog inputs
4 1 Relay output
Indicators:
• Power: 12-24 V power supply status
• Activity: Product status
• Serial1, Serial2, Serial3:
5
• Tx: Data sent on the RS485/RS422 serial port
• Rx: Data received on the RS485/RS422 serial port
• WAN: Connection status
6 Power button
Micro SD card slot
7
8 3 Digital inputs (ON-OFF or pulsed S0)
Version 2.05
préliminaire
12
2
1
8
USER MANUAL – WebdynSunPM
3
9
3
4
13
11
10
12
