Technical Specifications; General Specifications - Webdyn WebdynSunPM User Manual

AC1601-02
AC1101-01
AC1101-02
AC1102-01
AC1401-01
AC1402-01
AC1403-01
AC1201-01
AC1201-02
AC1301-01
AC1301-02
AC1302-01
AC1302-02
AC1001-01
AC1002-01

Technical Specifications

1.6.1 General specifications

Specifications
Power supply
Battery
Consumption
Dimensions
Box
Version 2.05
préliminaire
USB / TIC extension 1 non-modulated input
4-20 mA ambient temperature sensor
Modbus ambient temperature sensor
4-20 mA surface temperature sensor
Class C pyranometer
3 m pyranometer cable
20 m pyranometer cable
Modbus slave 8 ON-OFF inputs / 6 relay outputs
Modbus slave 16 ON-OFF inputs
Single phase electricity meter
Single phase electricity meter with relay
Three phase electricity meter
Three phase electricity meter with relay
Irradiation and temperature sensor & 3m Modbus cable
Irradiation sensor
Descriptions
+12V
supported on 12V)
or
+24V
650mAh 3.7V, Lithium-polymer
P: 5 W
Pmax: 10W
155x 106 x 58mm
9 DIN rail modules
RoHS compliant
DIN EN 60715 TH35
DIN VDE 0470-1
DIN 43880 size 1
USER MANUAL – WebdynSunPM
700mA (some functions are not
350mA
14
