Colour code:
• Black: Fixed text
• Blue: Device-specific information or data.
Where:
• fileDefinitionName: Definition file name for the Inputs/Outputs

4.1.3.3 Device header (Modbus, inverters)

The device data file header is the following:
DEVICEINDEX;NumDevice_1
Protocol_1;fileDefinitionName_1
...
...
DEVICEINDEX;NumDevice_N
Protocol_N;fileDefinitionName_N
Colour code:
• Black: Fixed text
• Blue: Device-specific information or data.
Where:
• NumDevice_N: The device "index" in the connection interface configuration file for
device N (see section 3.1.2.2.2: "Definition file content")
• fileDefinitionName_N: Definition file name for device N

4.1.3.4 Data

Data formatting is identical regardless of the device or interface.
The reported values are raw and must be linked to the configuration on the device or the
interface in its definition file. The IS must interpret the data using the raw data file and the
definition file to be able to apply factors A and B and the unit for each variable. (see section
3.1.2.2.2: "Definition file content")
The "action" field value for the device or the interface defined in its definition file is used for
the following action:
"Action" Description
code
0 no values are reported.
1 the parameter value is reported.
2 the min, max and mean values are reported.
4 the instant value is reported.
