Parameter
Below is a modem configuration example:
type;pin;apn;login;password;authentification
MODEM;;m2minternet;;;None
In this example, the PIN code is empty, the APN is set to "m2minternet", the login and
password are empty and the authentication type is defined as "None".
When editing this file using Excel, the following display is shown using the CSV format:
type
MODEM
If the file is modified using "Excel" type spreadsheet software, the format may be
modified and the ";" delimiters replaced by ",", making it unusable by the
concentrator. Always make sure to indicate the delimiter format when saving.
3.1.2.1.3.2 Ethernet connection configuration
Ethernet interface configuration is based on the following parameters:
Parameter
Type Device type.
The possible values are:
Ip The local IP address assigned to the Ethernet
interface.
This value has an effect on the local IP address at
which the box can be contacted on the relevant
Ethernet interface.
This field cannot be empty
Mask This field contains the subnet mask used jointly
with the configured IP address.
This field cannot be empty
Gateway Routing device configuration to use for the
concentrator to be able to communicate with
devices not present on its local network.
DNS1 IP address for a DNS server the concentrator is to
use to resolve names.
Version 2.05
préliminaire
The possible values are:
• None: No authentication requested
by the remote server
• PAP: PAP type authentication
requested by the remote server
pin apn
m2minternet
Description
• LAN1: to configure the LAN 1 interface
• LAN2: to configure the LAN 2 interface
USER MANUAL – WebdynSunPM
Description
login password
Default value
authentification
None
Default value
LAN1 for the first line
LAN2 for the second line
192.168.1.12 for the first line
192.168.2.12 for the second line
255.255.255.0
