For the files generated by the installer/integrator, there are no file naming rules. The file name
is free form. There are no rules.
For the files generated by SunSpec detection, the name is composed as follows:
<uid>_SunSpec_<Category>_<Manufacturer>_<Model>_<Options>_<Protocol>.csv:
• Category: the device type. Currently only the "Inverter" type is used.
• Manufacturer: the manufacturer name. The value is obtained from the
"Manufacturer" field in the SunSpec tables
• Model: model name. The value is obtained from the "Model" field in the SunSpec
tables.
• Options: options detected on the device. The value is obtained from the "Options" field
in the SunSpec tables
• Protocol: the protocol name. The values are:
o modbusRTU: for a device on the serial connection
o modbusTCP: for modbus devices on Ethernet
3.1.2.2.1.4 SMA
The SMA file names are defined as follows:
<uid>_SMA_<Model>.csv:
• Model: is generated automatically from the SMA-Net protocol "Model" information

3.1.2.2.2 Definition file content

The file is in csv format, it is composed of text rows each composed of ";" delimited fields.
The first row in the file contains the following information:
Protocol ; Category ; Manufacturer ; Model
The fields are configured as follows:
Field Description
Protocol Protocol name used for this device. The possible values are:
Category Device category This name will be displayed as is on the local web site.
Manufacturer Manufacturer name. This name will be displayed as is on the local web site.
Model Device model name. This name will be displayed as is on the local web site.
Version 2.05
préliminaire
• modbusRTU: the device is accessed using the modbus RTU serial
connection
• modbusTCP: the device is accessed using TCP connection
• io: the device is of the IO type
• tic: the device is of the TIC type
