- A login and a password: The parameters are used to define the FTP account to be used.
- A root directory: The root directory can be "/", the FTP server root directory, or a series
of sub-directories (for example: "/WebdynSunPM/00CF4/").
You can configure your concentrator remotely from your FTP server. This is only possible if
your WebdynSunPM is properly configured to upload and synchronise its configuration on an
FTP server.
Server tree structure:
The FTP server must have the tree structure specific to the WebdynSunPM product. The
concentrator proposes one by default but it can be customised. This architecture must exist
on the FTP server before the first connection because the concentrator does not create the
directories.
Below the root directory, the FTP server must have the following directories:
Name
/CONFIG
/DEF
/SCRIPT
/CERT
/DATA
Version 2.05
préliminaire
Rights
Read/Write Contains the configuration files.
The concentrator configuration uploaded by
the concentrator is in the following format:
"<uid>_config.ini"
The
uploaded by the concentrator is in the
following format:
"<uid>_daq.csv"
The
uploaded by the concentrator is in the
following format:
"<uid>_var.ini"
The
uploaded by the concentrator is in the
following format:
"<uid>_scl.ini"
Read/Write Contains the definition files.
The definition file has the following format:
"<uid>_<interface>_<comment>.csv"
Read/Write Contains the script files.
The script file has the following format:
"<comment>.lua"
Read/Write Contains the certificates.
The certificate has the following format:
"<comment>.pem"
Write Contains the collected data.
The data file name is in the following format:
"<uid>_<interface>_<timestamp>.csv.gz"
USER MANUAL – WebdynSunPM
Description
connection interface
connection schedule
connection schedule
configuration
configuration
configuration
