The file name is defined as follows: Take the device uid as explained previously and suffix
"_daq.csv" to it. Thus, in the previous example, the generated file name will be
"WPM00BDE4_daq.csv".
If the base configuration is created using the embedded web server, this file is created
automatically the first time the concentrator connects.
If the file is detected when connecting to the FTP server, it is uploaded and the configuration
is applied immediately regardless of the local configuration.
Contrary to the previous files, this one is in CSV format (delimiter ";"), i.e. directly editable
using spreadsheet software such as Microsoft Excel®.
This file has 4 separate parts:
• Modem configuration
• Ethernet connection configuration
• Serial port configuration
• Connected device configuration
3.1.2.1.3.1 Modem configuration
Modem configuration is based on the following parameters:
Parameter
Type
Pin
APN
Login
Password
Authentification
Version 2.05
préliminaire
Description
Device type.
The only possible value here is "MODEM"
Is used to define the modem PIN code
value, if defined.
This field contains the APN name to connect
to using the SIM card.
This APN depends on the selected operator
and subscription.
This field MUST NOT be empty to be able to
use the modem connection.
Login to use to establish the connection.
This login is provided by the operator and
depends on it and the subscription type.
This field can be empty.
Password for the login for authentication to
use to establish the connection. This
password is provided by the operator and
depends on it and the subscription type.
This field can be empty.
Authentication type to use for the
connection. This value depends on the
operator and subscription type. This
information is supplied by the operator.
USER MANUAL – WebdynSunPM
Default value
MODEM
None
