Technical Specifications - Webdyn WebdynSunPM User Manual

Fixing
Weight
Operating temperature
Storage temperature
Humidity
Pollution rating
Certification
Regulation

1.6.2 Technical specifications

Specifications
Memory capacity for data
SD card
Cellular Interface Modem
SIM format
Ethernet interface
USB interface
Serial interface
Input/Output interface
Version 2.05
préliminaire
USER MANUAL – WebdynSunPM
REACH compliant
VBG 4
IEC 529
Non leak tight
DIN rail
0.330 kg
-5 °C / +40 °C
Storage: -20 °C / +85 °C
25 - 75 %
2
RED
ROHS
REACH
: CE marking created in the framework
of European technical
legislation. It is mandatory for all products
covered by one or more
regulatory texts (directives or regulations)
: Symbol indicating that the waste must
be collected via a specific channel and must
not be disposed of as household waste.
: Symbol indicating that the product
must be recycled.
Descriptions
DDR3 SDRAM: 512 Mb
Flash eMMc: 8 Gb in total (50Mb max per
defined device)
MicroSD MMC/SD/SDIO (up to 32 Gb)
GSM/GPRS/EDGE/3G modem
• 2G (EDGE, GSM, GPRS): B1 and B8
• 3G (HSPA): B1 and B8
Antenna: External SMA
Standard SIM (mini SIM) 2FF format
1.8V compatible
2 10/100 Mbits/s ports available
1 USB2.0 port
3 RS485/RS422 ports
4 analog 0/10V or 4/20mA inputs
harmonisation
European
15
