• 0: variable disabled. The variable will not appear in the data files
• 1: the variable is of the parameter type and is read only. It will not therefore
appear in the data files.
• 2: the variable is of the min/max/mean type. In that case 3 files fields will
contain this variable in the data file to log the minimum, maximum and mean
value for this data.
• 4: the variable is of the instant value type. The data read at collection time will
be stored in the data file using a single field.
• 8: the variable is of the alarm type. When a change in the value of this variable
is detected, an alarm is triggered. The data read at collection time will be stored
in the data file using a single field.
The "Info1", "Info2", "Info3" and "Info4" fields are specific to each protocol and are therefore
configured as follows:
3.1.2.2.2.1 TIC
Field Description
Info1 This field will be used to indicate the variable description. This is the name
of the variable to be collected that makes it possible to identify it in the TIC
flow. It is the label.
Info2 Not used
Info3 Not used
Info4 Not used
3.1.2.2.2.2 IO
Field Description
Info1 Input/output type.
The authorised values are:
• 1:analog input (0-10V or 4-20mA)
• 2: digital input
• 3: switching relay output
Info2 Input/output number
The authorised values are:
• 1 to 3: if "Info1" equal to 1 (analog input)
• 1 to 4: if "Info1" equal to 2 (digital input)
• 1: if "Info1" equal to 3 (switching relay output)
Info3 Clarification on the input or output type.
• If "Info1" equals 1 (analog input), the authorised values are:
• If "Info1" equals 2 (digital input), the authorised values are:
• If "Info3" equals 3 (relay type), this field is not used
Info4 Not used
Version 2.05
préliminaire
o 1: analog input of the 4- 20ma type
o 2: analog input of the 0-10V type
o 1: ON-OFF input
o 2: S0 pulse input
USER MANUAL – WebdynSunPM
