If the base configuration is created using the embedded web server, this file is created
automatically the first time the concentrator connects.
If the file is detected when connecting to the FTP server, it is uploaded and the configuration
is applied immediately regardless of the local configuration.
The following configuration parameters must be added to the file:
• Connection method configuration:
o SERVER_Address=<FTP server name to use for the configuration>
o SERVER_TYPE=ftp
o If the connection is by Ethernet:
o If the connection is by modem:
o FTP_Login=<Login to use for the FTP server>
o FTP_Password=<Password for the FTP server login>
The configuration parameter details for this file are in section 9.1Appendix A: "_config.ini" file
3.1.2.1.2 "<uid>_var.ini" file
The "_var.ini" file contains the scheduling list configured on the concentrator.
The file name is defined as follows: Take the device uid as explained previously and suffix
"_var.ini" to it. Thus, in the previous example, the generated file name will be
"WPM00BDE4_var.ini".
If the base configuration is created using the embedded web server, this file is created
automatically the first time the concentrator connects.
If the file is detected when connecting to the FTP server, it is uploaded and the configuration
is applied immediately regardless of the local configuration.
The file has one row per configured schedule. Each row contains the schedule number with
its corresponding parameters.
The format is the following:
Variable
SCHEDULE_Params[n]
SCHEDULE2_Params[n]
Where "n" is replaced by the schedule index number. The number starts at 0.
The parameters for each row are in the following format:
Version 2.05
préliminaire
▪ SERVER_Interface=ethernet
▪ SERVER_Interface=modem
Definition
Schedule parameters for the
Server 1 connection
Schedule parameters for the
Server 2 connection
USER MANUAL – WebdynSunPM
Default value
47
