Sci.ini" File - Webdyn WebdynSunPM User Manual

o Parameters: 1. A wait of 1ms is applied between 2 frames.
o Category: Inverter.
o Model: WR21TL09
o DefFIle: WPM00C715_SMA_Inverter_SMA_WR21TL09.csv. The definition file
• modbus ethernet:
o Index: 1. Index for the second modbus device configured on the concentrator
o Interface: 192.93.121.23:502. This value indicates that the device is of the
o Name: ethernet_192.93.121.23_502_126. The name that will be displayed on
o Address: 126. This device responds at the modbus 126 address
o AcqPeriod: 600. The acquisition period is set to 600 seconds, or one record
o Timeout: 5000. The timeout is set to 5000ms
o SerialNumber: empty. Not applicable
o Parameters: 1. The connection is kept alive.
o Category: Inverter
o Model: Solar_Inverter
o DefFIle:
When editing this file using Excel, the following display is shown using the CSV format:
index interface name address
IO Io
TIC1
0 SERIAL1 Serial1_ 0
52224
1 192.93.12 Etherne 126
1.23:502 t_192.9
3.121.2
3_502_
126
If the file is modified using "Excel" type spreadsheet software, the format may be
modified and the ";" delimiters replaced by ",", making it unusable by the
concentrator. Always make sure to indicate the delimiter format when saving.

3.1.2.1.4 "_sci.ini" file

The "_sci.ini" file contains the list of scripts configured on the concentrator.
The file name is defined as follows: Take the device uid as explained previously and suffix
"_sci.ini" to it. Thus, in the previous example, the generated file name will be
"WPM00BDE4_scl.ini".
