3.1.2.2.1 Definition file naming

The file name is free and can be modified by the client at will, the gateway will use the name
given in the daq.csv file.
The automatically generated files are prefixed with the concentrator ID of which the default
value is "WPM" followed by the last 6 digits of the MAC address of the device that generated
them.
The concentrator ID can be modified by the client, however, if it is modified after a file has
been generated, there will be no resulting modification of the file name or its declaration in
the daq.ini file.
The prefix is separated from the remainder of the file name by an underscore. The purpose of
this is to prevent overwriting files that previously existed at the IS level.
The files will have a csv extension. If another extension (.ini for example) is given in the daq
file, it will be accepted.
Files generated automatically or created by the local web interface will be named as follows:
3.1.2.2.1.1 TIC
The TIC file names are defined as follows:
File name
<uid>_TIC_CBEMM.csv
<uid>_TIC_CBEMM-ICC.csv
<uid>_TIC_CBETM.csv
<uid>_TIC_CJE.csv
<uid>_TIC_ICE2Q.csv
<uid>_TIC_ICE4Q.csv
<uid>_TIC_PME-PMI.csv
<uid>_TIC_SAPHIR.csv
<uid>_TIC_LINKY.csv
3.1.2.2.1.2 IO
The IO file names are defined as follows:
<uid>_IO.csv
3.1.2.2.1.3 Modbus
There are two types of modbus file:
• The files generated by the installer/integrator
• The files generated by SunSpec auto-detection
Version 2.05
préliminaire
Description
Single phased electronic multi-tariff "blue" meter (CBEMM).
Single phased electronic multi-tariff "blue" meter (CBEMM ICC
evolution).
Three phased electronic multi-tariff "blue" meter (CBETM).
Three phased electronic "yellow" meter (CJE).
"Interface Clientèle Emeraude 2 quadrants" electronic three phased
meter (ICE-2Q).
"Interface Clientèle Emeraude 2 quadrants" electronic three phased
meter (ICE-4Q).
Electronic three phased "PME-PMI" meter
Three phased electronic multi-tariff "SAPHIR" meter (CBETM).
Standard mode electronic "LINKY" meter.
