INVT Goodrive200A Series Operation Manual page 75

GD200A series VFD
Function
Name
code
QUICK/JOG
P07.02 function
selection
Shifting
sequence
P07.03
selection of
QUICK/JOG
Description
Ones: Function of QUICK/JOG key
0: No function
1: Jogging. Press QUICK/JOG to begin the
jogging running.
2: Shift the display state by the shifting key. Press
QUICK/JOG to shift the displayed function code
from right to left.
3: Shift between forward rotations and reverse
rotations. Press QUICK/JOG to shift the direction
of the frequency commands. This function is only
valid in the keypad commands channels.
4: Clear UP/DOWN settings. Press QUICK/JOG
to clear the set value of UP/DOWN.
5: Coast to stop. Press QUICK/JOG to coast to
stop.
6: Shift the running commands source. Press
QUICK/JOG to shift the running commands
source.
7: Quick commission mode(committee according
to the non-factory parameter)
Note: Press QUICK/JOG to shift between forward
rotation and reverse rotation, the VFD does not
record the state after shifting during powering off.
The VFD will run according to parameter
during next powering on.
Tens: Keypad lock selection
0: Do not lock keypad buttons
1: Lock all the keypad buttons
2: Lock part of the keypad buttons (lock PRG/ESC
key only)
Note: If the tens is 1, press PRG+DAT keys three
times, and all the keypad buttons will be locked;
Keep DAT key pressed down while pressing V key
three times can unlock keypad buttons.
Setting range: 0x00–0x27
When P07.02=6, set the shifting sequence of
running command channels.
0: Keypad control→terminals control
→communication control
-68-
Function parameters
Default
value
0x01
P00.13
0
Modify
◎
○
