INVT Goodrive200A Series Operation Manual page 67

GD200A series VFD
Function
Name
code
S1 terminal
P05.14 switching-on
delay time
S1 terminal
P05.15 switching-off
delay time
S2 terminal
P05.16 switching-on
delay time
S2 terminal
P05.17 switching-off
delay time
S3 terminal
P05.18 switching-on
delay time
S3 terminal
P05.19 switching-off
delay time
S4 terminal
P05.20 switching-on
delay time
Description
Sln FWD
OFF→
ON
ON
ON
ON
OFF
/
ON→
OFF
/
Note: for the 2-wire running mode, when
FWD/REV terminal is valid, the VFD stop because
of the stopping command from other sources,
even the control terminal FWD/REV keeps valid;
the VFD won't work when the stopping command
is canceled. Only when FWD/REV is relaunched,
the VFD can start again. For example, the valid
STOP/RST stop when PLC signal cycles stop,
fixed-length stop and terminal control (see
P07.04).
The function code defines the corresponding
delay time of electrical level of the programmable
terminals from switching on to switching off.
Si electrical level
Si valid invalid
Switcn-on
delay
Setting range: 0.000–50.000s
-60-
REV Direction
ON Forward
OFF Reverse
Forward
OFF→
ON
Reverse
/
Decelerate
to stop
/
valid invalid
Switcn-off
delay
Function parameters
Default
Modify
value
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
