GD200A series VFD
Function
Name
code
P17.05 Motor speed
P17.08 Motor power
P17.09 Output torque
Evaluated
P17.10 motor
frequency
P17.11 DC bus voltage
ON-OFF input
P17.12
terminals state
ON-OFF output
P17.13
terminals state
Digital
P17.14
adjustment
Torque
P17.15
reference
P17.16 Linear speed
P17.17 Length
P17.18 Counting value
AI1 input
P17.19
voltage
Description
Display the rotation speed of the motor.
Range: 0–65535RPM
Display current motor power
Range: -300–300%
Display the current output torque of the VFD.
Range: -250.0–250.0%
Evaluated frequency of motor rotor
Range: 0.00Hz–P00.03
Display current DC bus voltage of the VFD
Range: 0.0–2000.0V
Display current Switch input terminals state of the
VFD
Range: 0000–00FF
BIT8
HDI
BIT4 BIT3
S5 S4
Display current Switch output terminals state of
the VFD
BIT3 BIT2
RO2 RO1
Range: 0000–000F
Display the adjustment through the keypad of the
VFD.
Range : 0.00Hz–P00.03
Display the torque given, the percentage to the
current rated torque of the motor.
Setting range: -300.0%–300.0%
(motor rated current)
Display the current linear speed of the VFD.
Range: 0–65535
Display the current length of the VFD.
Range: 0–65535
Display the current counting number of the VFD.
Range: 0–65535
It is implemented through the analog
potentiometer on the keypad for the 0150G/018P
and lower models; not available for the
-95-
BIT7 BIT6 BIT5
S8 S7 S6
BIT2 BIT1 BIT0
S3 S2 S1
BIT1 BIT0
HDO Y
Function parameters
Default
Modify
value
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
