INVT Goodrive200A Series Operation Manual page 64

GD200A series VFD
Function
Name
code
S6 terminal
P05.06 function
selection
S7 terminal
P05.07 function
selection
S8 terminal
P05.08 function
selection
HDI terminal
P05.09 function
selection
Polarity
P05.10 selection of the
input terminals
Description
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time option terminal 1
22: ACC/DEC time option terminal 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse Pause(stop at the current frequency)
27: Traverse reset(return to the center frequency)
28: Counter reset
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Length reset
33: Cancel the frequency change setting
temporarily
34: DC brake
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-exciting command
40: Clear the power consumption
41: Keep the power consumption
61: PID pole switching
When the terminal acts as acceleration/
deceleration time selection function, it is required
to select four groups of acceleration/deceleration
time via state combination of these two terminal
(while terminal 1 choose 21, terminal 2 choose 22)
Terminal1 Terminal2
(21) (22)
OFF OFF
ON OFF
OFF ON
ON ON
The function code is used to set the polarity of the
input terminals.
Set the bit to 0, the input terminal is anode.
-57-
ACC/DEC time
Parameters
selection
ACC/DEC time 1 P00.11/P00.12
ACC/DEC time 2 P08.00/P08.01
ACC/DEC time 3 P08.02/P08.03
ACC/DEC time 4 P08.04/P08.05
Function parameters
Default
Modify
value
◎
0
◎
0
◎
0
◎
0
○
0x000
