Fault code Fault type
EEP EEPROM fault
PIDE PID feedback fault
bCE Braking unit fault
Grounding shortcut
ETH1
Grounding shortcut
ETH2
Velocity deviation
dEu
STo
Maladjustment fault
Time reach of
END
factory setting
parameters autotuning and
the standard parameter is
huge
Autotune overtime
Error of controlling the write
and read of the parameters
Damage to EEPROM
PID feedback offline
PID feedback source
disappear
Braking circuit fault or
damage to the braking pipes
The external braking
resistor is not sufficient
The output of the VFD is
fault 1
short circuited with the
ground
There is fault in the current
detection circuit
The actual motor power
fault 2
sharply differs from the VFD
power.
The load is too heavy or
fault
stalled
The control parameters of
the synchronous motors not
set properly
The autotune parameter is
not right
The VFD is not connected
to the motor
The actual running time of
the VFD is above the internal
setting running time
Possible cause
-115-
Fault tracking
What to do
Check the motor connection
and set the parameter.
Check if the upper limit
frequency is above 2/3 of the
rated frequency.
Press STOP/RST to reset
Change the main control
panel
Check the PID feedback
signal
Check the PID feedback
source
Check the braking unit and
change new braking pipe
Increase the braking
resistor
Check if the connection of
the motor is normal or not
Change the hall
Change the main control
panel
Set motor parameters
correctly.
Check the load and ensure
it is normal
Increase the detection time
Check whether the control
parameters are normal
Check the load and ensure
it is normal
Check whether the control
parameter is set properly or
not
Increase the maladjustment
detection time
Ask for the supplier and
adjust the setting running
time
