1-4
Chapter 1, Module Overview
Parameter
Pollution Level
ESD
Radiated Immunity
Outputs per module
Inputs per module
Power Consumption
Power Dissipation (within
module) (current mode)
Peak Inrush Current
Module Scan Time for all analog
channels
Isolation
Between channels and backplane
Between Channels and chassis
ground
Wire size
Wire Strip Length
Recommended Tightening
Torque:
RoHS
Pollution Degree 2 is an environment where, normally, only non-conductive pollution occurs except that
1
occasionally a temporary conductivity caused by condensation is expected.
User's Manual Pub. 0300307-01 Rev. A
Specification
Meets Pollution Degree 2 requirements
Meets CE requirements for operating ESD category B at 6 kV
indirect (coupling plate).
10 V/m with 1 kHz sine-wave 80% AM from 80...2000 MHz
10 V/m with 200 Hz square wave 50% Pulse 100% AM at 900
MHz
10 V/m with 200 Hz square wave 50% Pulse 100% AM at 1890
MHz
10 V/m with 1 kHz sine-wave 80% AM from 1000...2000 MHz
10 V/m with 1 kHz sine-wave 80% AM from 2000...2700 MHz
4 current/voltage output channels
4 current/voltage input channels
Maximum 110 mA at 5 V (4.5 V to 5.5 V) from backplane; (0.55
W)
Maximum 125 mA at 24 V (19.9 V to 26.4 V) from backplane
Nominal 24V; (3 W)
Less than 4 W at 50 Ohm resistance load on all output channels
Less than 3.6 W at 250 Ohm resistance load on all output
channels
Less than 3.2 W at 500 Ohm resistance load on all output
channels
Less than 150 mA for +5 V from backplane and rail
Less than 500 mA for +24 V from backplane
Less than 3 seconds. For the normal case, no communication
error occurs between channels and backplane.
50 VAC working Reinforced isolation tested at 2 kVDC for 1
minute.
50 VAC working Reinforced isolation tested at 2 kVDC for 1
minute.
#16 to #28 AWG
0.375 in.
0.25 N-m (2.2 lb-in)
Meets European RoHS component standards (January 2015 and
earlier).
.
1
