Compliance to
European
Union Directives

Power Requirements

Chapter 2
Installation and Wiring
This chapter covers the following subjects:
•

Compliance to European Union Directives

• Power Requirements
• General Considerations
• Mounting
This product is approved for installation within the European Union and EEA
regions. It has been designed and tested to meet the following directives.

2.1.1 EMC Directive

The 2085-IF4XOF4-SC modules are tested to meet Council Directive
2014/30/EU Electromagnetic Compatibility (EMC) and the following standards,
in whole or in part, documented in a technical construction file:
• IEC 61000-6-4 Electromagnetic compatibility (EMC)–Part 6-4: Generic
standards–Emission standard for industrial environments
• IEC 61000-6-2 Electromagnetic compatibility (EMC)–Part 6-2: Generic
standards–Immunity for industrial environments
• EN 61131-2 Programable controllers - Part 2: Equipment requirements
and tests
The backplane power and the analog inputs of the device are only to be supplied
by an Isolated Secondary Limited Energy Low Voltage source.
The module receives power through the bus interface from the +5 VDC (4.75 to
5.4 V)/+24 VDC (19.9 to 26.4 V) system power supply. Current rating is for +5
V is 110 mA maximum; for +24 V it is 125 mA maximum. Power rating is 3
Watts maximum:
5 VDC 24 VDC
110 mA 125 mA
