3-2 Chapter 3: Configuring the 2085-IF4XOF4-SC Using CCW
2085-IF4XOF4-SC
AOP
User's Manual Pub. 0300307-01 Rev. A
End
User
PC Workstation
with CCW
Micro800 Expansion I/O Module Backplane
±10 V
0-10 V
0-5 V
0-20 mA
4-20 mA
Micro800-
IF4XOF4-SC
Analog
Combination
Module
Spectrum Controls, Inc. also provides a custom configuration software utility,
MCC, that you may use to send module configuration settings to CCW easier.
You use the module's AOP to configure your module. The AOP is available in
the CCW software. If not available, or a newer revision is released, see Appendix
A about how to manually import a module AOP to CCW.
To view information about the AOP:
1. Use RA's Module Profile Tool 2.0. This tool may be launched from
within CCW by selecting the Module Profile Tool option from the
CCW Tools menu:
2. When prompted by Windows User Account Control, to confirm that you
wish to run the program, click Yes button.
USB/Ethernet/Serial
Connection
Micro800
Expansion I/O
Modules
Micro850/870
Controllers
2080
Expansion
I/O module
Backplane
2080
Expansion
I/O
Modules
