Spectrum Controls Micro800 User Manual page 47

Word
Module &
Channel
Index
15
Input Data
AI_09 Signed 16-bit INT
Ch0
Input Data
AI_10 Signed 16-bit INT
Ch1
Input Data
AI_11 Signed 16-bit INT
Ch2
Input Data
AI_12 Signed 16-bit INT
Ch3
FW
AI_13 Major
Revision
Bit Name
3:0 O<n>
7:4 I<n>
8 CAL
9 SN
10
DRV
14:11 Not Used
15 MF
Chapter 3: Configuring the 2085-IF4XOF4-SC Using CCW
High Byte
14 13 12 11
Module Status (AI_00)
If any of the following bits are set in this word, the most significant bit (Module
Fault) will also bet set as a global indication. If any hardware fault is set by the
module or channels, the fault is permanent until the module is power-cycled.
Bit definitions for Module Status are provided in the table below:
Description
General Status Output <Channel>
General status bit. If a bit is set (1) then there is an error associated with
that Output channel (check Output Status bits for the indicated channel).
Bit 0 = Output Channel 0, Bit 1 = Channel 1, etc.
General Status Input <Channel>
General status bit. If a bit is set (1) then there is an error associated with
that input channel (check Input Status bits for the indicated channel).
Bit 4 = Input Channel 0, Bit 5 = Input Channel 1, etc.
Internal use only
Internal use only
Invalid Power Supply
Hardware fault that indicates the module 15 V power supply to output
drivers is not available.
Bits marked as Not Used are set to 0.
Module Fault
Set as global fault if any hardware or channel has fault.
Output Channel Status (AI_02:01)
Each word holds output status bits for two channels output. The high byte is for
odd channel and the low byte is for even channel.
Bits
10 9 8 7 6
Minor
User's Manual Pub. 0300307-01 Rev. A
Low Byte
5 4 3 2 1
3-19
0
