Input Description
Input Bias Currents and Impedance
Open Wire Detection Current
(Voltage range only)
Current input impedance
Voltage input impedance

Environmental Specifications

Table 1-4. EMC Specification Table
Environmental Tests
Radiated Emissions
Conducted Emissions
ESD immunity
(Performance Criteria B)
Radiated RF immunity
(Performance Criteria A)
EFT/B immunity
(Performance Criteria B)
Surge transient immunity
(Performance Criteria B)
Conducted RF immunity
(Performance Criteria A)
Magnetic Field
(Performance Criteria A)
User's Manual Pub. 0300307-01 Rev. A
Specification
Approximately 100 µA during open wire checks for a duration of
one channel scan time, with a 470 Hz filter.
250 (±10%) ohm
15 Mohms except during open circuit detection
The 2085-IF4XOF4-SC module has the following environmental specifications:
Industry Standards
(Enclosure) Class A, 30 MHz – 1 GHz
Group 1, Class A (AC Mains), 150 kHz – 30 MHz
6 kV Indirect (Coupling Plate)
6 kV Contact Discharge (to points of initial contact)
8 kV Air Discharge (to points of initial contact)
10 V/M with 1 kHz sine-wave 80% AM from 80...2000 MHz
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at 900
MHz
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at 1890
MHz
10 V/M with 1 kHz sine-wave 80% AM from 1400...2000 MHz
10 V/M with 1 kHz sine-wave 80% AM from 2000...2700 MHz
Signal Ports:
± 2 kV at 5 kHz for 5 minutes, Criteria B
Power Ports:
± 2 kV at 5 kHz for 5 minutes, Criteria B
Signal Ports:
± 2 kV line-earth {CM}at 2Ω on shielded ports
Power Ports
± 2 kV CM at 12Ω
± 1 kV DM at 2Ω
10 V RMS with 1 kHz sine wave 80% AM from 150 kHz...80
MHz on signal and power ports
30 ARMS/m
